特點Features1.使用平面銑刀切削,刀刃遲鈍時可再利用軌道座的旋轉角度,使刀片再利用,大大的提高了刀片的價值,等於節省一半刀片的價格2.可有兩種調整模式:舊式L型倒角(圖示一)+新專利-新式V型

特點Features
1.使用平面銑刀切削,刀刃遲鈍時可再利用軌道座的旋轉角度,使刀片再利用,
大大的提高了刀片的價值,等於節省一半刀片的價格
2.可有兩種調整模式:舊式L型倒角(圖示一)+新專利-新式V型倒角(圖示二)
3.新式V型倒角-切削時較省力,切削後表面光滑平順,不會起伏不定
A. Adopt with flat face mill cutting. In order to save the cutter costs.
B. Available for 2 functions adjusting. The original for L type chamfering (Fig 1);
The new for V type chamfering (Fig 2).
C. For V type chamfering: save energy. Also the surface of workpeice will be more smoothly
After chamfered.
MODEL JT-100C.100R.100C+R
Capacity, Original-L Model 0~3m/m
Capacity, New-V Model 0~5m/m (2 times processing)
Speed 11000r.p.m
Option speed Variable speed, 2800~11000r.p.m
Table size 100×70mm
Length of guide rails ψ100×ψ28×6mm
Motor 100V~240V,50/60Hz,1PH
Non Load Motot 670W 6.0A
Weight 2.4KGS/ 2.8KGS
Packing 38×13×14cm
Measurement 0.24Square feet
